1m (3ft) MTP®-12 (Female) to MTP®-12 (Female) OS2 Single Mode Elite Trunk Cable, 12 Fibers, Type B, Plenum (OFNP), Yellow
1m (3ft) MTP®-12 (Female) to MTP®-12 (Female) OS2 Single Mode Elite Trunk Cable, 12 Fibers, Type B, Plenum (OFNP), Yellow
| Kablo Türü | Fiber Optik |
|---|---|
| Kablo Uzunluğu | 1 m, 5 m |
| Wavelength | 1310 nm/1550 nm |
| Operating Temperature | -10 to +70°C (14 to 158℉) |
| Jacket | Plenum (OFNP) |
| Fiber Mode | OS2 9/125μm SM |
| Connector A | US Conec MTP® Female (Pinless) |
| Connector B | US Conec MTP® Female (Pinless) |
“MTP® Female to MTP® Female OS2 9/125 Single Mode Trunk Cable
MTP® trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. With US Conec MTP® connectors and Corning SMF-28® ultra optical fiber, it is optimized for 40G QSFP+ PLR4, 100G QSFP28 PSM4, 400G OSFP DR4/XDR4 and 400G QSFP-DD DR4/XDR4 optics direct connection and high-density data center applications.
Please note: The US Conec MTP® connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors.”
